İNŞAAT VE YAPI ÇELİKLERİ 1.7045 – 1.8906
| KARŞILAŞTIRMALI ULUSLARARASI STANDARTLARI | |||||||||
| İNŞAAT VE YAPI ÇELİKLERİ | |||||||||
|
ALMANYA W-Nr. DIN |
BELÇİKA NBN |
FRANSA AFNOR |
BÜYÜK BRİTANYA B.S. |
İTALYA UNI |
JAPONYA JIS |
İSVEÇ SS |
RUSYA GOST |
İSPANYA UNE |
A.B.D. AISI/SAE/ASTM |
| 1.7045 42Cr4 | 42 C 4 TS | 530 A 40 | 41 Cr 4 | SCr 440 | 2245 | 40Ch | F. 1202 – 42 Cr 4 | 5140 | |
| 1.7106 60SiCr7 | 60 SiCr 8 | 60 SC 7 | 60 SiCr 8 | F. 1442 – 60 SİCr 8 | 9262 | ||||
| 1.7131 16MnCr5 | 16 MnCr 5 | 16 MC 4 |
527 M 17 590 H 17 590 M 17 |
16 MnCr 5 | 2173 | 18ChG |
F. 1516 – 16 MnCr 5 F. 1517 – 16 MnCr 5 |
5115 | |
| 1.7147 20MnCr5 | 20 MC 5 | 20 MnCr 5 | SMnC 420 H | 18ChG | F. 150.D | 5120 | |||
| 1.7176 55Cr3 | 55 Cr 3 | 55 C 3 |
525 A 58 525 A 60 525 H 60 |
55 Cr 3 |
SUP 9 (A) |
2253 | 50ChGA | F. 1431 – 55 Cr 3 |
5155 5160 |
| 1.7218 25CrMo4 | 25 CrMo 4 |
25 CD 4 25 CrMo 4 |
708 A 25 | 25 CrMo 4 (KB |
SCM 420 SCM 430 SCCrM 1 |
2225 |
20ChM 30ChM |
F.8372 – AM 26 CrMo 4 F.8330 – AM 25 CrMo 4 F.1256 – 30 CrMo 4-1 |
4130 |
| 1.7220 34CrMo4 | 34 CrMo 4 |
34 CrMo 4 35 CD 4 |
708 A 37 |
34 CrMo 4 KB 35 CrMo 4 35 CrMo 4 F |
SCM 432 SCCrM 3 SCM 435 H |
2234 |
AS38ChGM 35ChM 35ChML |
F. 8331 – AM 34 CrMo 4 F. 8231 – 34 CrMo 4 F. 1250 – 35 CrMo 4 F. 1254 – 35 CrMo 4 DF |
4135 4137 |
| 1.7223 41CrMo4 | 41 CrMo 4 | 42 CD 4 TS |
708 M 40 3111-5/1 |
41 CrMo 4 |
SCM 440
|
2244 | 40ChFA |
F. 8332 – AM 42 CrMo 4 F. 8232 – 42 CrMo 4 F. 1252 – 40 CrMo 4 |
4140 4142 |
| 1.7225 42CrMo4 | 42 CrMo 4 |
42 CD 4 42 CrMo4 |
708 A 42 708 M 40 709 M 40 |
38 CrMo 4 KB 42 CrMo 4 G 40 CrMo 4 |
SCM 440 (H) SNB 7 |
2244 |
F. 8332 – AM 42 CrMo 4 F. 8232 – 42 CrMo 4 F. 1252 – 40 CrMo 4 |
4140 4142 |
|
| 1.7228 50CrMo4 | 50 CrMo 4 | 708 A 47 | SCM 445 (H) | 4150 | |||||
| 1.7242 16CrMo4 | 18 CrMo 4 | 18 CrMo 4 | SCM 418 H | F. 1550 – 18 CrMo 4 | |||||
| 1.7262 15CrMo5 | 12 CD 4 |
SCN 415 (H)
|
F. 1551 – 12 CrMo 4 | ||||||
| 1.7264 20CrMo5 | 18 CD 4 |
SCM 420 H SCM 421 |
F. 1559 – 18 CrMo 4-1 | ||||||
|
1.7335 13CrMo4-5 13CrMo4-4 |
14 CrMo 45 |
15 CD 3.5 15 CD 4.5 |
620-440 620-470 620-540 1501-620; 621 |
14 CrMo 3 16 CrMo 3 |
SFVA F 12 | 2216 |
12ChM 15ChM |
F. 2631 – 14 CrMo 4 5 |
A 182 – F 11; F 12 A 387 Gr. 12 Cl.2 |
| 1.7337 16CrMo4-4 | 15 CD 4.5 | 18 CrMo 4 5 KW; KG | 2216 | 15ChM | A 387 Gr. 12 Cl. 2 | ||||
| 1.7361 32CrMo12 | 32 CrMo 12 | 30 CD 12 | 722 M 34 | 32 CrMo 12 |
|
2240 | F. 124.A | ||
| 1.7380 10CrMo9-10 |
12 CD 9.10 10 CD 9.10 |
1501 – 622/515 1501 – 622/690 1502 – 622; 3604 – 622 |
12 CrMo 9 10; KW; KG G 14 CrMo 9 10 |
SFVA F 22 A; B SCMV 4 SCPH 32-CF |
2218 | 12Ch8 | TU.H |
A 182 F 22 A 387 Gr. 22 Cl. 2 |
|
| 1.7715 14MoV6-3 | 13 MoCrV 6 | 1503 – 660 – 460 | F. 2621 – 13 MoCrV 6 | ||||||
|
1.8159 51CrV4 50CrV4 |
50 CrV 4 |
50 CrV 4 51 CrV 4 |
735 A 51 735 H 51 |
50 CrV 4 | SUP 10 | 2230 |
50ChGFA 50ChFA |
F. 1430 – 51 CrV 4 |
6145 6150 |
| 1.8507 34CrAlMo5 | 34 CrAlMo 5 | 30 CAD 6.12 | 34 CrAlMo 7 | F. 1741 – 34 CrAlMo 5 | A 355 Cl.D | ||||
| 1.8509 41CrAlMo7 | 41 CrAlMo 7 | 40 CAD 6.12 | 905 M 39 | 41 CrAlMo 7 | SACM 645 | 2940 | 38ChMJuA | F. 1740 – 41 CrAlMo 7 |
A 355 Cl.A E 71400 G 71406 |
| 1.8515 31CrMo12 | 31 CrMo 12 | 30 CD 12 | 722 M 24 |
30 CrMo 12 31 CrMo 12 |
2240 | F. 1712 – 31 CrMo 12 | |||
| 1.8523 39CrMoV13-9 | 39 CrMoV 13 |
897 M 39 3 S. 132 |
|||||||
|
1.8902 S420N StE 420 |
FeE 420 KG N E 420 RIFP |
FeE 420 KG; KW | SM 490 A; B; C; YA; YB | 2143 | 16G2AF | AE 420 KG | A 633 Gr. E | ||
| 1.8903 S460NL; TStE 460 | E 460 FP | 4360-55 EE | FeE 460 TD | AE 460 KT | |||||
|
1.8905 P460N StE 460 |
FeE 460 KG N E 460 RIFP |
4360-55 F | FeE 460 KG; KW | SM 520 B | 2143 | 18G2AFps | AE 460 KG | A 633 Gr. E | |
| 1.8906 S460QL; TSIE; 460V | S 460 Q | 4360-55 F | FeE 460 VKT | ||||||
